75 Bushel Manure Spreader
Model 1200 25 year Free Replacement
Warranty Against Rot on all Pressure Treated Lumber Floor and
The Model 1200 spreader is for the horseman
or hobby farmer with larger amounts of manure to spread. Three
times the capacity of our model 600 spreader at a very economical
Any 18 HP, or larger, utility tractor
is acceptable. The large wheels provide the necessary traction
to drive the beater and drag chain, even in snow and mud. The
unique double beater bar enables excellent spreading action while
being fed by the continuous motion drag chain.
Great for Maneuvering within Barn Aisles!!
Heavy structural steel angle
Long life pressure treated floor and side boards are easily
removed for user flexibility.
Big 27 - 8.50 x 15 industrial tires with agriculture bar
Individual rope pull clutching. One for the beater, and
one for the drag chain.
Double beater design for more even disbursement.
Continuous motion drag chain for smoother discharge (no
70 cubic feet heap capacity (75+ bushels or 10 - 15 wheelbarrow
Guides built-in to accept removable end gate which eliminates
rear spillage during transport.
Load bed is 84" long x 40" wide x 21" high
Overall length is approximately 120" long x 62"
Removable lumber is pressure treated 1" x 6"
Structural steel framework is mostly 1/4" thick
Heavy duty drive V-Belts are 5/8 x 81"
Drag chain (apron) is #55 detachable link style
Transmissions include #40 roller chains and sprockets
Shipping Weight: 450 lbs.
or Call 1-800-335-1880
